Vacuum Insulated Glass: The Next Leap in Window Performance
By Total Care Windows Sat Sep 27 20257 minutes
What is Vacuum Insulated Glass (VIG)?
Vacuum insulated glass, or VIG, represents a groundbreaking innovation in window technology. Unlike traditional double or triple glazing, VIG utilizes a hermetically sealed vacuum layer between two panes of glass, effectively eliminating conductive and convective heat transfer. This results in remarkably high thermal insulation within an ultra-thin profile, making VIG an attractive solution for both new constructions and retrofits where space or weight is a concern.How Does VIG Outperform Conventional Glazing?
The core advantage of vacuum insulated glass lies in its superior thermal resistance. By removing air (and thus, almost all heat transfer) from the cavity between panes, VIG can achieve insulation values (U-values) rivaling or surpassing triple glazing, but with the thickness of single glazing. This is particularly beneficial in heritage restorations or contemporary minimalist designs where bulky frames are undesirable.- Minimal thickness—often under 10mm total, enabling slender frames
- Exceptional thermal insulation (U-values as low as 0.4 W/m²K)
- Significant reduction in condensation risk
- Lower overall window weight compared to triple glazing
- Enhanced acoustic attenuation due to vacuum barrier
“Vacuum insulated glass offers architects and homeowners the unique ability to combine energy efficiency with uncompromised aesthetics.”
Key Applications and Use Cases for VIG
Vacuum insulated glass is rapidly gaining traction across a spectrum of architectural applications. Its slim construction and high performance make it ideal for settings where traditional glazing solutions fall short, especially in projects with strict energy codes or architectural preservation requirements.- Historic building retrofits where maintaining original sightlines is crucial
- High-performance residential windows in space-constrained frames
- Commercial facades seeking to maximize daylight while minimizing energy loss
- Passive house and net-zero energy building projects
- Specialty applications such as display cases, cold rooms, and transportation
Comparing VIG to Double and Triple Glazing
To truly appreciate the leap VIG represents, it helps to compare its specifications with those of conventional double and triple glazing. The table below summarizes key performance metrics and physical characteristics.| Glazing Type | Typical Thickness | U-Value (W/m²K) | Weight |
| Double Glazing | 24-28mm | 1.1 - 1.6 | Medium |
| Triple Glazing | 36-44mm | 0.7 - 1.0 | High |
| Vacuum Insulated Glass | 8-12mm | 0.4 - 0.7 | Low |
Installation Considerations and Limitations
While VIG offers compelling benefits, it is not without considerations. Specialized edge sealing and support pillars within the vacuum cavity are required for durability. Not all window manufacturers offer VIG-compatible frames, and initial costs can be higher than conventional glazing. However, the long-term energy savings and unique design flexibility often justify the investment.- Requires precise installation to maintain vacuum integrity
- Limited size availability compared to standard glazing
- Potential for higher upfront costs, offset by energy savings
- Compatibility with select frame systems only
“Investing in vacuum insulated glass is about future-proofing your building envelope for both performance and design flexibility.”
